CAD Audio Astatic 1700VP Mini Condenser Variable Polar Pattern Microphone w/ Stand Mount - DEMO

Note: Boom stand is not included.

The 1700VP Variable Polar Pattern Microphone from CAD is designed to accurately capture vocals, speech, choirs, musical performances, and similar scenarios. It features an unobtrusive miniature profile, a remote control with variable polar patterns, a low-frequency roll-off switch, and an adjustable 56" carbon fiber boom pole. The 1700VP system allows you to accurately dial in the appropriate polar pattern, minimizing noise and maximizing clarity. The microphone also includes a 30' cable and is suitable for installation in houses-of-worship, halls, auditoriums, theaters, conference centers, and with other large-audience applications.

• Unobtrusive miniature profile
• Can be used with choirs, overhead ambiance, group vocals, speech, sermons, and similar applications
• Includes 56" adjustable carbon fiber boom and variable-pattern remote control
• Low frequency roll-off minimizes hum and ambiance
• Radio Frequency (RFI) rejection from PDAs, cell-phones, other wireless devices

Microphone

Capsule	Condenser
Polar Pattern	Cardioid, Figure-8, Omnidirectional
Pattern Selection	Switched

Performance

Frequency Range	40 Hz to 20 kHz
Maximum SPL	110 dB SPL
Impedance	135 Ohms
Sensitivity	-29 dBV/Pa
Equivalent Noise Level	22 dB A-Weighted
THD	1%

Connectivity

Output Connectors (Analog)

1 x XLR 3-Pin

Power

Operating Voltage	12 V 24 V 48 V
Operating Current Consumption	4.0 mA

Physical

Dimensions	ø: 0.79 x L: 1.69" / ø: 20 x L: 43 mm
Weight	1.1 oz / 31.19 g

Packaging Info

Package Weight	1.9 lb
Box Dimensions (LxWxH)	10.4 x 9.9 x 2.3"
